Electrical & Power Specifications

  • Output Current Range: $20\text{A}$ to $300\text{A}$ (fully adjustable via analog dial or digital control panel).

  • Input Voltage:

    • Standard Units: $220\text{V} – 240\text{V}$ AC (Single Phase, $50/60\text{Hz}$).

    • Heavy Industrial Units: Dual voltage ($220\text{V}/380\text{V}$) or pure 3-Phase ($380\text{V} – 415\text{V}$) to handle the high amp draw stably.

  • Rated Input Capacity: Approx. $9.5\text{kW}$ to $12\text{kVA}$ at peak output.

  • No-Load Voltage: $62\text{V} – 75\text{V}$ (ensures excellent arc striking capability, even with difficult rods).

  • Efficiency / Power Factor: ~85% efficiency with a $0.75 – 0.85$ power factor.
